Customized Thermal Shock Machine Small Compact Air Colling Type With Access Port

Name: Customized Thermal Shock Machine Small Compact Air Colling Type With Access Port
Brand: MENTEK
Price: 1 USD

Brand Name : MENTEK

Model Number : MTS3-27

Certification : CE

Place of Origin : China

MOQ : 1 Unit

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 30 sets per month

Delivery Time : 25-35 working days after order confirmed

Packaging Details : First protected by resin fiber and PP film, then put into Strong wooden case

Temperature Range : -20°C~150°C

Test Space : 25 to 1000Litres

Electronic : AC220V·50HZ/380V·50HZ

Meet Test Standard : IEC, ASTM, MIL, ISO etc

Interior material : SUS 304

Refrigeration : Unit cooling mode

Product Name : Thermal Cycling Chamber

Usage : Thermal Shock Testing

Contact Now

Customized Small Compact Air Colling Type Shock Test Chamber With Access Port

Mentek are Highly flexible for customization thanks to its rich experience in manufacturing environment test chambers since 1999, Our engineers understand this need of the industry well and offer the highest level of customisation like design modification or integration with other applications such as different sizes with custom color and sizes, access port.

Customized Thermal Shock Machine Small Compact Air Colling Type With Access Port

Application

Electronic parts
Home appliance
Auto parts
Aviation parts
LED lights
Plastics
Metals

Technical Sheet For Three Zone Thermal Shock Chamber

Model		MTS-50	MTS-100	MTS-150	MTS-200	MTS-300
Interior Volume		50L	100L	150L	200L	300L
Interior Dimension(cm)		3540H35	5040H50	6050H50	6550H62	9050H67
Temp Change Rate(with load)		5℃ ～20℃/m(Standard); 30/℃/m( Liquid Netrogen)
Hot/Low Temp Range(Testing Zone)		+60℃～+150℃			-10℃～-65℃
Hot/ Low Temp Range(Preheat-precool Zone)		+60℃～+200℃ (Pre heating zone)			0℃～-78℃ (Pre cooling zone)
Preheating Time(m)		RT to 150℃	RT to 150℃	RT to 150℃	RT to 150℃	RT to 150℃
		30	40	40	40	40
Precooling Time(m)		-40, -55℃, -65℃	-40, -55℃, -65℃	-40, -55℃, -65℃	-40, -55℃, -65℃	-40, -55℃, -65℃
		70,80,90	70,80,90	70,80,90	70,80,90	70,80,90
Power	(KW)	20,21,22	21,22,23	22,23,25	28,35,45	30,40,50
Temp Fluctuation		±0.5℃
Temp Conversion Time				≤10 seconds
Temp Recovery Time				≤5min
Temp & Humidity Deviation		±1℃～±2℃		±3％RH(＞75％RH);±5％RH(≤75％RH) (optional)
Standard configurations		1 Window, 1 Cable port, 1 Lamp, 4 Casters, 1 Power cable, 2 Stainless steel shelves
Standard Documentations		quality certification,test report ,user operaion manual for machine & controller
Safety devices		Electric leakage, fan overheat ,anti-dry ,compressor overheat & overpressure,power supply undercurrent,overheat, overcurrent, phase sequence, over-temperature protection devices
